Wheel Loader Tyres

In the process of assembling pneumatic loader tire, sometimes the tyre lock ring, retainer ring and movable seat are not installed properly. The tire in the process of inflation, once the tire lock ring pressure ring, will lead to lock ring, retaining ring and movable base pop-up, serious and even cause casualties. In order to ensure the safety of operators, fundamentally eliminate hidden dangers and improve work efficiency, we made a simple, practical, safe and effective tire inflation protection device. The tire inflation protection device consists of 1 pressing plates, 2 sets of hooks and 2 pin shafts. Hook hook hook and consists of two parts, the overall production can hook and the hook rod, can also be fixed by welding on the hook rod.

The diameter and spoke height of different types of tires are different. To improve the adaptability of the tire inflation protection device, a plurality of the hook hook. The hook body is vertically staggered distribution in the vertical direction of hook, projection on the level surface is staggered distribution, i.e. circumferential staggered.

The pressure plate and the hook are connected by a pin shaft, that is, the connecting slot is arranged at both ends of the pressing plate, and the top of the hook is inserted in the connecting slot. A pin hole is arranged at the top of the hook, and the pin shaft is passed through the pin hole, so that the hook can be installed on the pressing plate. When removing, just pull out the pin shaft.

In the tire, the pressing plate arranged in the tyre lock ring, ring and ring on the activities of the tire, spoke up on the hook. In the process of tire, tire lock ring, ring and ring up outside activities, hook hook will catch on the tire rim, the spokes to keep the tire. The pressing plate which is connected with the hook is tightly hung by the hook, and then the pressing plate is tightly pressed on the tyre lock ring, the retainer ring and the movable seat ring.

In the process of the tire, the device through the spokes by pressing up on the hook, press the tire lock ring, ring, ring activities, so as to avoid the tire lock ring, ring and ring out, eliminating the security risks. The tire inflation protection device has the advantages of simple manufacture, convenient operation and high working efficiency, and is suitable for the inflation protection of various large tires.
